XV506CS-16
Orientation: TEE
End 1 Type: FSAE
End 1 Size: 1
End 2 Type: FSAE
End 2 Size: 1
Description
| Minimum Operating Temperature: | -20 °F, -28 °C |
| Maximum Operating Temperature: | 425 °F, 218 °C |
| Locking Mechanism: | Non-Locking |
| Maximum Operating Pressure: | 206 bar, n/a |
| Connection Type: | NPT, Straight Thread, SAE J1926-1 |
| Body Material: | Carbon Steel |
| Ball Material: | Steel |
| Seat Material: | PTFE |
| Function: | Ball Valve |
| Orifice Size: | n/a |
| Product Type: | Ball Valve |
| Seal Material: | PTFE |
| Shape: | in-line |
| Configuration: | In-Line |
| Actuation Type: | Manual |
| Connection Size: | 1 inch |
| Handle Type: | Lever |
| Maximum Flow Rate: | n/a |
| Mounting Type: | Panel |
| Operation Type: | n/a |
| Specifications Met: | n/a |
| Connection 2 Thread Style: | SAE Straight Thread |
| Connection 1 Thread Style: | SAE Straight Thread |
| Handle: | Steel Lever |
| Connection 2 Thread Size (inch): | 1 5/16-12 |
| Connection 1 Thread Size (inch): | 1 5/16-12 |
| Maximum Working Pressure (psi): | 3000 |
| Shape: | In Line |
| Style: | Straight Thread Ends |
